Title:	Durable Bridges Using Glass Fiber Reinforced Polymer and Hybrid Reinforced Concrete Columns
Principal Investigators:	Chris Pantelides
University:	University of Utah
Status:	Completed
Year:	2020
Grant #:	69A3551747108 (FAST Act)
Project #:	MPC-609
RH Display ID:	15811
Keywords:	bridge construction, carbon fibers, columns, fiber reinforced polymers, glass fibers, posttensioning, reinforced concrete bridges, tendons (materials)

Abstract

The objective of this project is to investigate alternative methods for constructing bridge columns in high seismic regions using longitudinal Glass Fiber Reinforced Polymer (GFRP) bars and GFRP spirals; in addition, self-centering in terms of Carbon Fiber Reinforced Polymer (CFRP) post-tensioning of bridge columns and damage-resistant end joints as rocking devices will be utilized. Hybrid systems of reinforcement promote sustainable performance, long service life, and cost-effective maintenance of bridge columns in harsh weather. In addition, analytical models will be developed for self-centering in terms of post-tensioning of columns in bridges with CFRP corrosion-free tendons. The proposed hybrid systems consist of two cast-in-place (CIP) columns: one with two layers of all-GFRP longitudinal bars and spirals, and one with an inner layer of conventional steel longitudinal bars and a GFRP spiral, and an outer layer of longitudinal GFRP bars and spirals. In addition, two precast post-tensioning columns with resilient end joints will be investigated with the same hybrid reinforcement. Post-tensioning accommodating self-centering will be designed with high-strength CFRP tendons.

Project Deliverables

• [Final Report] Durable Bridges Using Glass Fiber Reinforced Polymer and Hybrid Reinforced Concrete Columns — MPC-23-511
  • View Research Brief
• [Webinar] Durable Bridges Using Glass Fiber Reinforced Polymer and Hybrid Reinforced Concrete Columns — Fiber reinforced polymer (FRP) composite materials have been studied and applied to reinforced concrete (RC) structures for strengthening or seismic retrofit...
