Project Details

Title:	Analysis of ABC Bridge Column-to-Footing Joints with Recessed Splice Sleeve Connectors
Principal Investigators:	Chris Pantelides
University:	University of Utah
Status:	Completed
Year:	2020
Grant #:	69A3551747108 (FAST Act)
Project #:	MPC-638
RH Display ID:	154945
Keywords:	bridge construction, columns, earthquake resistant design, footings, joints (engineering), precast concrete

Abstract

Accelerated Bridge Construction (ABC) has been implemented in bridge construction because it provides advantages for commuters in urban areas. Prefabrication of bridge structural components is a highly effective method and is one of the ABC methods of Prefabricated Bridge Elements and Systems (PBES) proposed by the Federal Highway Administration. There is a need to develop ABC column-to-footing joints for bridges located in moderate- and high-seismic regions. Robust analysis and design methods for such joints are an important component of this effort. Grouted splice sleeve connectors are assumed for assembling the column-to-footing joints. In the proposed research, where the bars are grouted at both ends of the splice sleeve connectors (GGSS). This research aims to understand the effect of recessing the GGSS inside the footing well below the column-to-footing interface. The gap between the end of the GGSS and the column-to-footing interface is assumed to be grouted inside corrugated steel ducts. The main goal of the research is to show using advanced analysis methods that such joints constructed with precast elements perform in a satisfactory manner similar to monolithic cast-in-place (CIP) joints. A second goal of the research is to develop guidelines for the seismic design of these joints.

Project Deliverables

• [Final Report] Analysis of ABC Bridge Column-to-Footing Joints with Recessed Splice Sleeve Connectors — MPC-22-473
  • View Research Brief
• [Webinar] Analysis of Bridge Column-to-Footing Joints — This webinar is based on MPC project 638, Analysis of ABC Bridge Column-to-Footing Joints with Recessed Splice Sleeve Connectors. Accelerated Bridge Construction...

Project Word Files

• Show project Word files
  • Full Description (Word, 339K)
  • UTC Project Information (Word, 23K)
